Solar Lighting Tower
Solar Lighting Tower
Lighting For Remote Locations
Construction sites,Parking lots and outdoor spaces,Roadworks and maintenance，Mining and remote locations,Temporary Security Needs.
High quality, More than 16 years of production experience，Products exported to more than 100 countries.
Option Parts
EQUIPMENT INFO
Model
Transport Dimension (L×W×H) Operate
Dimension (L×W×H) Weight
UST-900L
3400 x 1650 x 2700 mm
3400 x 3300x 2700 mm
1350kg
LIGHTING SYSTEM
Type of Lamp
Rate Power
Protection Class
Luminous Flux
llluminated Area
LED lights
4 x 100W
IP67
660,000lms
1868㎡
SOLAR SYSTEM
Solar Panel
Rate Power
Efficiency
Charge Time
Monocrystalline silicon
3 x 435W
22.30%
9.3hrs
BATTERY SYSTEM
Type
Capacity
Voltage
Work Temperature
Run Time
GEL
6 x 200Ah(14400WH)
12VDC
-20 ~ 55℃
CHARGING SYSTEM
Type
Rated Charge Current
Efficiency
System Voltage
Remote Monitoring
MPPT
60A
99.5%
24V DC
Optional
LIFTING SYSTEM
Type
Material
Max Height
Lifting System
Rotation
Wind Rating Speed
Telescopic Mast
Q235 Metal tube
7 meters
Manual/Electric/Hydraulic
Optional
100Km/h
TRAILER SYSTEM
Type
Standard
Tow Hitch
Brake system
Hand Brake
Stabilization leg
Suspension System
Transportation
Tyre & Rim
Mobile Single Axle Trailer
Australia/America/Europe
50mm Ball 2000kg
Electric Brake
/
4 pcs Manual
Spring Type
Truck,Crane,Forklift
215 75R 15LT
HYBRID SYSTEM(OPTIONAL)
Inverter
Batter Charger
Back-up Genset
Wind Turbine
3KW
2.5KW
3KW Gasoline
500W
DIMENSION QTY
20′ / 3 units
40′ / 7 units
